Technical Parameters:
● Scanning Modes: Convex array / linear array / micro-convex array
● Standard Configuration: R60/3.5M convex array probe
● Optional Configurations:
● Standard Configuration: R60/3.5M convex array probe
● Optional Configurations:
- R20/5.0MHz micro-convex probe
- 3.5MHz backfat linear array probe
- 6.5MHz rectal probe
● Image Storage: ≥ Built-in 8G non-volatile memory (data retained during power off), supports direct upload to PC
● Movie Playback: ≥64 frames
● Display Modes: B, B+B, B+M, M, 4B
● TGC (Time Gain Compensation): Total gain, 8-segment adjustable gain
● Image Processing: Grayscale correction, histogram
● Real-Time Depth Adjustment: Multi-level adjustable
● General Measurements: Distance, perimeter, area, volume
● Obstetric Measurements: Designed for obstetric measurement in horses, cattle, sheep, dogs, and cats
● Position Markers: 16 animal position markers
● Report Function: Automatic report generation
● Battery Life: ≥2 hours
● Video Output: PAL system
● Weight: 950g (including battery)
● Dimensions: 216mm × 147mm × 27mm
● Dust/Water Resistance: IP65
● Ports: Video, USB 2.0, multifunctional port (supports online upgrades, video output, real-time USB data upload)
● Screen Size: 5-inch LCD monitor
● Certification: CE certified
